STREAMLITE™ PIXEL RGBW

STREAMLITE™ PIXEL RGBW
Create diffused and dynamic pixel patterns with chasing effects driven by a pixel control system. Built on the popular STREAMLITE™ format, the pixel feature delivers billions of colors with dynamic linear lighting effects. Combine it with popular channels and accessories for a complete installation. Details & Downloads
SKU: Select Options Above

Features & Benefits

  • Dot-free lighting with dynamic effects
  • Up to 225 Lm/ft.
  • 20 ft. Max. Run
  • IC Chip - WS2814A
  • 7 Year Warranty

Product Specs

Cuttable Increments 4 in.
Dimmable Yes
Environment / IP Rating Indoor / Damp Location IP20
Max. Run Up to 20 ft.
Warranty 7 Year Limited
Description
Create diffused and dynamic pixel patterns with chasing effects driven by a pixel control system. Built on the popular STREAMLITE™ format, the pixel feature delivers billions of colors with dynamic linear lighting effects. Combine it with popular channels and accessories for a complete installation.
All Options
SKU Lumens / ft. Max. Run Color (CCT) Length
DI-24V-STMLT-RGBW-PIX-016 225 Up to 20 ft. RGBW 16.4 ft. Spool
Recommended Accessories
Power Supplies
HLG Series MEAN WELL Driver
The MEAN WELL HLG series of LED power supplies, available in 24V options ranging from 150W to 600W, offers high-efficiency and reliable power solutions for various lighting applications. These power supplies are designed with robust features such as active PFC, wide input voltage ranges, and multiple protection mechanisms, ensuring optimal performance and safety.
  Name
View in new tab
Color Controllers
Advatek's PixLite® LED Pixel Controllers
Boundless creativity unlocked with Advatek PixLite®LED pixel controllers. Regardless of the scale or complexity of your project, you can confidently deploy an Advatek pixel solution with optimal value, quality and performance.
  Name
View in new tab
