LINAIRE® Flex 3D Bend RGBW

Top

LINAIRE® Flex 3D Bend RGBW

LINAIRE Flex 3D Bend RGBW
LINAIRE® Flex 3D Bend RGBW
Multidirectional RGBW linear light delivering precision-grade illumination with flawless diffusion. Water-resistant and designed for seamless integration in architectural curves.


Explore Our Full Product Line for Scenic Applications


LINAIRE® Flex comes in static white and with multiple bend profiles, view the full product line offered at our LINAIRE® Flex Family page.


Product Note: Spools come with an IP67 rating; when trimmed and re-capped in the field the rating becomes IP65.

SKU: Select Options Above

Features & Benefits

  • Bends in both directions (top and side) for maximum versatility
  • Flexible, durable fixture with no visible dots
  • Water resistant for indoor and outdoor use
  • Full color RGBW
  • Factory assembly (IP67)
  • Field adjustable termination (IP65)

Product Specs

Connection Type RGBW
CRI 90+
Cuttable Increments 2.46 in.
Environment / IP Rating Factory Assembly (IP67), Field Adjustable Termination (IP65)
Input Voltage 24VDC
Max. Run Up to 16.4 ft.
Warranty 5 Year Limited
Description
Multidirectional RGBW linear light delivering precision-grade illumination with flawless diffusion. Water-resistant and designed for seamless integration in architectural curves. LINAIRE Flex features precision color rendering and high R-values for vivid, accurate lighting in demanding applications.
All Options
SKU CRI Environment / IP Rating Input Voltage Lumens / ft. Max. Run Average Lumens (per ft.) Power Option Color (CCT) Length Type Item
DI-24V-3D-LIN-RGBW-016 90+ Factory Assembly (IP67), Field Adjustable Termination (IP65) 24VDC 103 Up to 16.4 ft. 100+ Lm/ft. - 16.4 ft. spool RGBW Light Engine Only
DI-LIN-3D-DEC 24VDC N/A N/A N/A Accessory Only N/A N/A Accessory End Cap
DI-LIN-3D-MTCH-39 24VDC N/A N/A N/A Accessory Only N/A N/A Accessory Mounting - Channel
DI-LIN-3D-MTCL-2 24VDC N/A N/A N/A Accessory Only N/A N/A Accessory Mounting - Clips (2x)
DI-LIN-3D-SPINE-39 24VDC N/A N/A N/A Accessory Only N/A N/A Accessory Mounting - Spine Channel
Recommended Accessories
Power Supplies
OMNIDRIVE® X Dimmable Driver
Versatile driver for most high-performance dimming applications.
