LINAIRE® Flex 3D Bend Tunable White

LINAIRE Flex 3D
LINAIRE® Flex 3D Bend Tunable White
A 3D-bendable architectural light with flawless diffusion and adjustable color temperature for seamless integration into architectural curves. Water resistant with precision light quality and full diffusion for a dotless look.
Product Note: Spools come with an IP67 rating; when trimmed and re-capped in the field the rating becomes IP65.


LINAIRE® Flex comes in Static White, Warm Dim RGBW and with multiple bend profiles, view the full product line offered at our LINAIRE® Flex Family page.




Details & Downloads
SKU: Select Options Above

Features & Benefits

  • Bends in both directions (top and side) for maximum versatility
  • Precise diffused lighting with no visible LEDs
  • Consistent lighting performance to help with natural circadian rhythms
  • Water resistant for indoor and outdoor use, UV stabilized
  • 90+ CRI
  • Factory assembly (IP67)
  • Field adjustable termination (IP65)

Product Specs

Cuttable Increments 1.96 in.
Environment / IP Rating Factory Assembly (IP67), Field Termination (IP65)
Input Voltage 24VDC
Max. Run Up to 16.4 ft.
Warranty 5 Year Limited
Description
A 3D-bendable architectural light with flawless diffusion and adjustable color temperature for seamless integration into architectural curves. Water resistant with precision light quality and full diffusion for a dotless look.
All Options
SKU Input Voltage Lumens / ft. Max. Run Average Lumens (per ft.) Power Option Color (CCT) Length Type Item
DI-24V-3D-LIN-TW1840-016 68 Up to 32.8 ft. 200+ Lm/ft. - 16.4 ft. spool 1800K - 4000K Light Engine Only
DI-LIN-3D-DEC 24VDC N/A N/A N/A Accessory Only N/A N/A Accessory End Cap
DI-LIN-3D-MTCH-39 24VDC N/A N/A N/A Accessory Only N/A N/A Accessory Mounting - Channel
DI-LIN-3D-MTCL-2 24VDC N/A N/A N/A Accessory Only N/A N/A Accessory Mounting - Clips (2x)
DI-LIN-3D-SPINE-39 24VDC N/A N/A N/A Accessory Only N/A N/A Accessory Mounting - Spine Channel
